    Armoured Duplex Fiber Optical Patch Cord Indoor 3.0 SOS DX LC/UPC Connector

    Ask Lasest Price
    Brand Name : KEXINT
    Model Number : Amoured 9/125 LC-LC DX
    Certification : CE ROSS
    Price : Negotiation
    Payment Terms : D/A, L/C, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000+PCS+Per day
    Delivery Time : 7
    • Product Details
    • Company Profile

    Armoured Duplex Fiber Optical Patch Cord Indoor 3.0 SOS DX LC/UPC Connector

    Armoured Duplex Fiber Optical Patch Cord Indoor 3.0 Anti-rat Blue SOS DX LC/UPC


    Application :

    1; Telecommunication networks;

    2; Local area networks; CATV;

    3; Active device termination;

    4; Data center system networks;


    Features :

    1; Comply with IEC, Telcordia-GR-326-Core standards;

    2; Different size & color boot option;

    3; Low insertion loss; High return loss;

    4; 100% interferometer measurement;


    Technology specification:

    Technology specification ItemTechnology parameter
    Cable typeGJXFJPK-1~4B6a2
    Tight buffer colorBlue, orange, green, brown
    Tight buffer diameter mm0.85±0.05
    Fiber type9/125(G657A2)
    Strength memberAramid yarns
    Jacket thickness mm0.80±0.10
    Internal sub-cable Jacket colorWhite
    Cable outer sheath colorBlack (PANTONE 136C, ΔE≤4)
    Jacket materialLSZH SOS Armoured
    Internal sub-cable0.9(±0.1)
    Cable diameter mm3.0 (±0.2)
    Cable weight Kg/km15.0
    Min. bending radius mm10D
    Attenuation dB/km≦ 0.4at 1310nm, ≦ 0.3 at 1550nm
    Short tension N200
    Short crush N/100mm1000
    Operation temperature ℃-40~+70
    Installation temperature ℃-5~+60
    Transportation and storage temperature ℃-40~+70


    Armoured Duplex Fiber Optical Patch Cord Indoor 3.0 SOS DX LC/UPC Connector

    Our Service (KEXINT)
    1.Factor price
    2.Fast delivery
    3.OEM
