1000Mbps 4 Port Fiber Optic Media Converter Online SFP Module SX/LX
Data Buffer 256K
Media converters can be used anywhere in the network to integrate
newer technology with existing equipment to support new
applications, technologies and future growth. It provides you SC,FC
or ST connectors for your fiber optic cables and RJ45 for twisted
pair UTP cable connection. The maximum extension is up to 120km
over fiber.Instead of costly, across-the-board upgrades, media
converters can extend the productive life of the existing cabling
as well as the active equipment.
Features:
1. Auto negotiation function allows UTP ports to auto select
10/100/1000M and Full Duplex or Half Duplex.
2. The UTP port supports the connection of MDI/MDI-X auto
crossover.
3. Singlemode Fiber: the max distance up to 60km
4. Supporting the max 1536 byte Ethernet packet
5. Supporting flow control
6. Adopting internal power supply
Technical Specification
1. Operating standards: IEEE802.3z/AB, 1000Base-T and
1000Base-SX/LX
2. Ambient temperature: 0 ~ +50°C Storage temperature: -20 ~ +70°C
Humidity: 5% ~ 90%
3. Connector: UTP: RJ-45,10/100/1000Mbps; Fiber: SC,1000Mbps
4. Cable : UTP cable: Cat 5e or Cat 6 (the max distance up to 100m)
Fiber : singlemode : 8.3/125, 8.7/125, 9/125μm (distance 20-100km)
5. Flow control: Full Duplex: IEEE802.3x Half Duplex: back pressure
6. Power: DC 48V to DC 5V
7. MAC address table: 4K
8. Data Buffer: 256K
10/100/1000M Dual fiber
| Connector type | SC | SC | SC | SC | SC |
| Fiber type | Multi-mode | Single-mode | Single-mode | Single-mode | Single-mode |
| Wavelength | 850nm | 1310nm | 1310nm | 1550nm | 1550nm |
Max Distance | 62.5µm: 224m |
20Km |
40Km |
60Km |
80Km |
| 50µm: 550m |
| Min TX PWR | -11.0dBm | -9.0dBm | -4.0dBm | -8.0dBm | -3.0dBm |
| Max TX PWR | -6.0dBm | -5.0dBm | 0dBm | 0dBm | 0dBm |
| Sensitivity | < -18dBm | < -21dBm | < -24dBm | < -25dBm | < -25dBm |
| Link Budget | 7.0dBm | 12.0dBm | 20.0dBm | 17.0dBm | 22.0dBm |
10/100/1000M single fiber
| Connector type | SC | SC | SC | SC |
| Fiber type | Single-mode | Single-mode | Single-mode | Single-mode |
| Wavelength | 1310/1550nm | 1310/1550nm | 1310/1550nm | 1490/1550nm |
| Max Distance | 20Km | 40Km | 60Km | 80Km |
| Min TX PWR | -10.0dBm | -4.0/-8dBm | 0/-5.0dBm | -1dBm |
| Max TX PWR | -4.0dBm | 0dBm | 3/0dBm | 3dBm |
| Sensitivity | < -22dBm | < -25dBm | < -25dBm | < -25dBm |
| Link Budget | 12.0dBm | 20/17dBm | 25/20dBm | 24.0dBm |
Cable Connection of 10/100/1000M Series Gigabit Converter
| Port type | Cable Type | Max.Length |
| 10/100/1000BASE-T | Cat. 5, 5E UTP, RJ-45 | 100 meters |
| 1000BASE-SX | Multi-mode Fiber of 850n (62.5/125µm) | 220 meters |
| 1000BASE-SX | Multi-mode Fiber of 850nm (50/125µm) | 550meter |
| 1000BASE-LX | Single-mode Fiber of 1310nm(9/125um) | 10-100km |
LED Indication
Please refer to the following table for LED indication of
10/100/1000M Series Gigabit Converter
| LED | Status | Indication |
| power | ON | The Power is on |
| lnk/act | Flash | F1:FX Data,P1 and P2:TP Data |
| speed | ON | The Speed is 1000M |
Specifications of 10/100/1000M Series Gigabit Converter
| MODEL | 1,10/100/1000M Series | 2,10/100/1000M Series |
| STANDARD | IEEE802.3ab 1000BASE-T; | IEEE802.3ab 1000BASE-T; |
IEEE802.3z 1000BASE-SX | IEEE802.3z 1000BASE-LX |
| INTERFACE | RJ-45 part x 1 (10/100/1000 Mbps) SC connector Fiber port x 1 (1000 Mbps) |
TP CONNECTIONS | 10/100/1000BASE-T:UTP Category 5, 5E |
FIBER CONNECTIONS | 1000BASE-SX:62.5/125µm or 50/125µm Multi-mode fiber, SC/FC connector | 1000BASE-LX:9 or 10/125µm Single-mode fiber ,SC/FC connector |
LED INDICATIONS | lnk/act,speed,power |
| MAX.DISTANCE | 550m/220m | 10km and 20km,100km |
| ENVIRONMENT | Operating Temp:0~+70℃ Storage Temp:-40~+85℃ Humlblty:10~90% non-condensing |
| POWER | 5V 2A |
| NET WELGHT | 500 g |
| EMISSION | FCC Class A, CE |
Typical Optical Power Budget
| 10/100/1000M Series |
| Connector | SC | SC | SC | SC | SC |
| Wavelength | 850nm | 1310nm | 1310nm | 1310nm | 1550nm |
| Typical | 550m/220m | 10Km | 20Km | 30Km | 50-100Km |
| Min TX | -11dBm | -11.0dBm | -10.0dBm | -7.0dBm | -1～-6.0dBm |
Max TX PWR | -3.0dBm | - 3.0dBm | -1.0dBm | 0.0dBm | 0.0dBm |
| Sensitivity | -18dBm | -21.0dBm | -21.0dBm | -24.0dBm | -24.0dBm |
Link Budget | 8.5dB | 12.0dB | 15.0dB | 19.0dB | 19.0dB |
Installation
As with any electric device, you should place the equipment where
it will not be subject to extreme temperatures, humidity, or
electromagnetic interference. Specifically, the site you select
should meet the following requirements: Please follow the steps to
install the media converter. This Converter is aplug-and-play
device.
1. Turn off the power of the device/station in the network in which
the media converter will be installed.
2. Ensure that there is no activity in the network.
3. Attach fiber cable from the media converter to the fiber
network. The fiber connections must be Matched-Transmit socket to
receive socket
4. Attach a UTP cable from the 1000Base-Tx network to the RJ-45
port on the product
5. Connect the power cord to the media converter and check if the
power LED lights up. The TP Link and FX link LED will light when
all the cable connections are satisfactory.
6. Turn on the power of the device/station.
Packing & Delivery
The package will be packed according to standard export
requirements, customer satisfication is our target.
Label printing : Customer logo or kexint brand are available
Inner packing: 5pcs in one carton
Outer packing: the carton will be packed with sack, well protect
carton from dust and wet.
The transportation: By air ,by sea ,by DHL ,Fedex TNT ,UPS ...
1).Lead time
With more than 200 employees in my company,at least 10,000
connectors can be produced.
2).Research Department
With our separate research team,so we are albe to have products
made according to your requirements.
3).Qulity assurance
Every product will be tested to be of good quality.Meanwhile free
samples can be supplied for your test.
The guarantee period is 10 years.So if there are problems with the
goods,replacement will be available.
