CAT 6A High Speed Copper Lan Network Cable Common Computer Cat6 Ethernet STP UTP FTP

1, CAT6a Lan Cable Specifications

1) CONDUCTOR

* Raw material of the conductor: solid bare copper

* Conductor Dia.: 0.575±0.003mm (23AWG)

2) INSULATION

* Raw material of the conductor: F-PE

* Quantity:4 twisted pairs

Blue/white-blue; Green/white-green;

Orange/white-green; Brown/white-brown;

* Insulation Dia. : 1.45±0.005mm

* Average thickness: 0.3875 mm

* Minimum point thickness: 0.0.385mm

3) TWISTED PAIRS SCREEN: Aluminum foil

4) SHEATH

* Sheath material: LSZH

* Nominal Dia.: 7.3 ± 0.2mm

* Average thickness: 0.65mm

* Minimum point thickness: 0.55mm

2, Mechanical Properties

· Conductor insulation material: halogen free Foam/Skin material

· Cable jacket material: halogen-free, flame-retardant material

· Application area: dray as well as humid rooms

· Temperature (moved): 0°C to 50°C

· Operating temperature: -20°C to +60°C

· Min. bending radius for one-time bending: 4×O.D.

· Min. bending radius during installation: 8×O.D.

3, Application:

1. We have a professional production team.
2. Ability to meet customer OEM needs
3. We passed the ISO9001 certification system
4. Our customers are widely distributed, including the United States, Brazil, Russia, Spain, South Africa, Australia ...

      KEXINT which was founded in the year 2007 is a high-tech enterprise specialized in telecom communication network equipment research and development (R&D), manufacturing, marketing, and providing application solutions and technical services .

     Its main products include fiber optic cable, fiber distribution box, fiber optical patchcord , MPO/MTP , and optical splitter (PLC/FBT/WDM), fast connecter , fiber optic adapters, fiber optic attenuators ,We have more than 11 years of experience in passive fiber optic products . In 2016 , we also established OLT/ONU R&D and production. Products are widely used in telecommunications, broadcasting and other fields. Television, power engineering, and other industries. The main market distribution: Russia and other CIS, South Africa, Europe, South America, etc. The company promises: quality and integrity first

 Rich experiences in passive production of fiber optical products ensure the reliable stabilities of its high quality and excellent performances of its goods. It obtains the good reputations all these years from customers around the earth for its short lead-time, fast delivery, and timely after-services.
