| Hardware Specifications |
| Data Interfaces | Provide 8 GPON OLT ports |
| Provide 16 standalone GE WAN Interfaces (including
8*10/100/1000Base-T ports and 8*1.25G SFP Optical Transceiver or
1000Base-T SFP Copper Transceiver) |
| Management Interfaces | Provide one 10/100Base-T RJ45 out-band management interface |
| Out-band management interface via any GE WAN interface |
| Provide RS232 serial configuration port |
| Data Switch | Use L3 Ethernet switch, 128Gbps switch capability with no any
blocking |
| LED indications | RUN, ALM, PW1, PW2 indicates the status of system running, alarm
and power supplies |
| PON1 to PON8 indicates LINK and Active status of each PON port |
| GE1 to GE8 indicates LINK and Active status of each GE WAN
interface |
Power Supply Weight | 220V/1A AC power supply or -48V/3A DC power supply |
| Support two sources power supply with pluggable power supply module |
| Typical power consumption 50W |
| Case Temperature | 6.8Kg |
| Size | 0～55℃ |
| Data Interfaces | 440mm(Length)* 391mm(Width)* 44mm(Height) |
| Software Functions |
| GPON Standard | Compliance with ITU-T G.984.x standard and CTC 2.1 technical
requirements |
| DBA | Support fixed bandwidth, guaranteed bandwidth, best-effort
bandwidth and priority configurations |
| Support Dynamic Bandwidth Allocation (DBA) |
| Security | Support ONU S/N + password authorization |
| Support ONU LOID authorization |
| VLAN | Support 4096 VLANs adding, transparent, translation and deletion |
| Support VLAN based on port, MAC, Ethernet protocol and IP sub-net |
| Support VLAN stacking (QinQ) |
| MAC Learning | Support 32K MAC address |
| Line rate MAC address learning by hardware |
| Support MAC limitation based on port, VLAN and link aggregation |
| STP | Support IEEE 802.1d (STP), 802.1w (RSTP) spanning tree protocols |
| Multicast | Support IGMP Snooping and IGMP Proxy |
| Support IGMP v1/v2 |
| QoS | Support 802.1p priority queue scheduling |
| Support SP,WRR and SP+WRR scheduling algorithms |
| ACL | Rule according to destination IP, source IP, destination MAC,
source MAC, destination protocol port number, source protocol port
number, SVLAN, DSCP, TOS, Ethernet type, IP priority, IP packet
protocol type etc |
| Packet filtering according to above rules |
| Cos setting, IP priority setting, mirroring, rate limitation and
port re-direction according to above rules |
| Flow Control | Support IEEE 802.3x duplex flow control |
| Support port rate limitation |
| Link Aggregation | Support 8 link aggregation group, 4 member ports per group |
| Mirroring | Support port mirroring for WAN interfaces and PON ports |
| Log | Support log output mask according to alarm level |
| Support log output to terminal, file and log server |
| Alarm | Support 4 levels alarms (Critical, Important, minor and warning) |
| Support 6 alarm types (communication, QoS, process failure,
hardware and environment) |
| Support alarm output to terminal, log and SNMP network management
server |
| Performance statistics | Performance sampling period from 1 to 30s |
| Support 15 minutes performance statistics for WAN interfaces, PON
ports and ONU UNI ports |
| Maintenance | Support OLT configuration saving, and restore to factory
configuration |
| Support OLT on-line upgrading |
| Support ONU off-line service configuration and automotive
configuration deployment |
| Support ONU remote upgrading and batch upgrading |
| Management | Support local or remote CLI configuration |
| Support SNMP v1/v2c network management, support in-band and
out-band network management |
