    Handheld Fiber Optic Tools Splicer Mini Electric Fusion Machine KL-500 1.3Kg

    Ask Lasest Price
    Brand Name : KEXINT
    Model Number : KL-500
    Certification : CE UL ISO-9001
    Price : 1136.36$
    Payment Terms : D/A, D/P, T/T, Western Union, MoneyGram, L/C
    Supply Ability : 10+PCS+Day
    Delivery Time : 5
    • Product Details
    • Company Profile

    Handheld Fiber Optic Tools Splicer Mini Electric Fusion Machine KL-500 1.3Kg

    Handheld Fusion Splicer KL-520E Mini Fusion Machine With 8 English French Portuguese Russian Spanish


    1: Core-Core or Clad-Clad Alignment

    2: PAS Technology

    3: X&Y views dispaly or X/Y single display

    4: Handheld & portable

    5: Size: 125×105×113 (mm)

    6: SOC available

    7: 3-in-one fiber clamp

    8: 3.5 inch color LCD

    9: Software update via USB port


    Fiber diameterCladding diameter:80-150μm
    Fiber countSingle
    Fiber cleaved length12-16mm (Coating diameter:250μm)
    Actual average splice loss0.02dB(SM),0.01dB(MM),0.04dB(DS),0.04dB(NZDS)
    Typical splicing timeTypical 6 sec (standard SM fiber)
    Return loss>60dB
    Splicing modeAuto Calibrate Normal Special
    Fiber aligning methodMeticulous,Core,Clad,Manual
    Splicing program53 (templet), 40(user)
    Tube heating program9 (templet),24(user)
    Tube typical heating timeTypical 30 sec
    Protection sleeve length60mm, 40mm
    Storage of splice result4000 results, 20 parameter per result
    Fiber image magnification120X (X or Y view),60X (X and Y view)
    Battery capacityTypical 300 cycles (splice/tube heaty)
    Monitor3.5 inch color LCD monitor
    Tension test2N
    Electrode life2500
    TerminalUSB
    Power supplyAC 100-240V with AC adapter
    Inner Li-battery (5200mAh) DC 13.5V
    Operating condition0-5000m above sea level, -10-50°
    Max wind velocity of 15m/s
    Dimension125mm(L)×105mm(W)×113mm(H)
    Weight1.3Kg including battery

    Handheld Fiber Optic Tools Splicer Mini Electric Fusion Machine KL-500 1.3KgHandheld Fiber Optic Tools Splicer Mini Electric Fusion Machine KL-500 1.3Kg

    Handheld Fiber Optic Tools Splicer Mini Electric Fusion Machine KL-500 1.3Kg
