This product integrates the function of splicing with splitting,suitabel for the straight through or branch connection,and terminal connection in optical system, as well as protection connection for cables and distribution pigtails. The cables can be spliced with indoor cables by splitting,to meet the requirement of traditional network.

Specification:

a.High impact plastic, standard user interface
b.Suitable for 1x8 SC adapter with pigtail
c .Anti-UV,shocking resistance
d.Wall mount
e.Unique middle panel≥180°,clear area for splicing and distribution, less cross-connection for cables

Operation manual:

1.Install adapters
2. Strip and clean the cable, keep it 0.8~1.2m long and 30-50mm long of the strength member, and insert cable through inlet, fix
it by cable clamp, and fix strength member by special clamp.
3.Put the fiber to the tray,and let the end in the splicing slot after coiling
4.Install PLC splitter in the tray,and connect pigtails with adapters,and put the pigtails in the splicing slot, splice with the
incoming cables.(it can be used splicing only)
5.close the cover, plug outgoing pigtails through sealing rubber
6.Install the box with expansion screws, finish installation

Applications:

1.Optical LAN & WAN & CATV
2.FTTH project & FTTX
3.Testing instruments
4.Optical fiber communication networks
5.PON Networks
6.Optical Signal Distribution

Our advantages:

1.Good reply: Your inquiry related to our products or price will be replied within 24 hours.
2.OEM&ODM: We can help you to design or put your logo and company name into products.
3.Remote Technical support&Full Technical Document
4.Warranty: 1 year warranty( While the warranty is not responsible for those broken by violence or updated with other brands.)
5.English software, English Indicator
6.Professional, Very competitive price
7.Large Stock, Fast Delivery
8.Quality Assurance

Specification:

Techinical data:
Fiber bend radius	≥40mm
Splice tray excess loss	≤0.01dB
Temperature Range	- 40℃ + 60℃
Anti lateral pressure	≥2000N / 10 cm
Shock resistance	≥20N.m
