KEXINT High Power 1550nm 2U PON WDM GPON Solution CATV 12 24 36 Ports

Performance characteristics:
1.Adopts world top brand pump lasers and the OFS fiber of United
States, advanced LG switch low-power circuit design, greatly
reducing the overall power consumption and heat.
2.Perfect APC, ACC, ATC control, users use in different networks,
good ventilation design and temperature-controlled fan, ensure the
long life and high reliability of PUMP laser.
3.Using digital control chip, remote or local output power
adjustable.
4.Built-in low-noise preamplifier eliminates the need for cascaded
EDFA, allowing input light to be as low as -5dBm, greatly reducing
CNR and MER degradation.
5.Excellent protection circuit design, with light detection,
optical return loss monitoring. Great protection of lasers and
light path safety.
6.The total output optical power is optional: 2-10W (33-40dBm);
7.Demultiplexer for 1310/1490/1560nm EPON and GPON. It greatly
facilitates network applications with PON. Low noise figure (type ≤
4.5dB, Max ≤ 5.0dB);
8.The front panel LCD provides the operating parameters and alarms
of the entire unit. RJ45 provides serial communication and SNMP
network management interface; Carrier-grade dual power hot backup,
CPU assignable power.
9.The front panel can be removed and replaced flexibly according to
the number of output ports; Can add a built-in optical switch
module to facilitate the expansion of the device function; Cooling
fan supports online replacement;

Applications:
The KXT-56Axx series high power amplifier is a high power
multi-output optical fiber amplifier with a gain spectrum bandwidth
of 1535~1565nm. It is mainly designed for CATV or 1~8 continuous
strip channels (ITU wavelength) applications. It provides a
flexible, low-cost solution for large-scale FTTH coverage of CATV
systems in large and medium-sized cities.
KXT-56Axx can achieve single-wavelength cable TV transmission, CWDM
single-fiber three- wave, flat-gain type, DWDM; its reliable and
excellent performance ratio between the main application of FTTH,
FTTB, DBS, MMDS, FTTX pon, is to build CATV large Medium-sized
optical fiber transmission network is an important equipment.

Block diagram:

Limit parameter:

Technical parameters
KXT-56Axx
Max wavelength
1535-1565nm
Minimum input power
-10dBm
Max input power
+10dBm
Limited working temperature
-25℃ ~+70℃
Limited working voltage
AC90~265V&DC30~72V&DC30~72V

Technical parameters:
Technical parameters
KXT-56Axx
Wavelength
1535-1565nm
Input power
-5dBm~+10dBm(normal input -2dBm~+5dBm)
Output power
33dBm~40dBm(WDM -1dBm)
Output port
SC: 16/32/64；LC: 32/64/128
Each output power
10~23dBm or customized
Noise
＜ 5.0dB(Pin=0dB)
Polarization dependence loss (PDL)
＜ 0.3dB
Polarization dependence gain (PDG)
＜ 0.4dB
Polarization mode dispersion
(PMD)
＜ 0.3dB
Pump leakage power
＜ -30dBm
Echo loss
≥ 56dB
Optical connector
SC/APC&SC/UPC&LC/APC&LC/UPC
Supply voltage
220V(AC90V~265V)&110V(AC90V-130V)&48V(DC30~72V)
Consumption
≤100w
Working temperature
-5℃ ~+42℃
Storage temperature
-40℃ ~+80℃
Working relative humidity
5~95%
Product net size
465(L)*480(W)*89(H)
Package dimension
640(L)*640(W)*200(H)
