    Single Mode Green Small Fiber Optic Adapters MPO To APC Without Flange

    Ask Lasest Price
    Brand Name : KEXINT
    Model Number : MPO/APC adaptor
    Certification : CE/ROHS/ISO9001
    Price : USD 1.12~1.46
    Supply Ability : 500000 Piece/Pieces per Week
    Delivery Time : 7-14 working day
    • Product Details
    • Company Profile

    Single Mode Green Small Fiber Optic Adapters MPO To APC Without Flange

    Single Mode Green Small Fiber Optic Adapters MPO To APC Without Flange​


    Product Description
    The MPO/APC adapter, also known as an MPO/APC coupler, is designed with MPO female connections on both ends to connect two MPO patch cords together for up to 12 optical fibers. MPO fiber optic coupler has a compact design, accommodating 4, 8, or 12 fiber ribbons. The key is orientated opposite, key-up to key-down, and engineered for precision alignment. They are made from durable UL 94V-0 and polyethermide material colored green. The spring clip is made of stainless steel and designed with a spring loaded sliding mechanism to make sure the adapter is locked into place.


    Applications:
    Fiber-to-the-Antenna (FTTA) Automation and Industrial Cabling Surveillance Systems Broadcast Military Communications BBU, RRU,RRH, LTE

    itemValue
    Model NumberMPO/APC adaptor
    TypeFiber Optic Adapter
    Place of OriginChina,Guangdong
    Brand NameKEXINT
    UseFTTX
    Warranty Time2years
    NetworkNone
    Connector typeMPO/MTP
    Return LossSM/UPC≥50dB, SM/APC≥60dB, MM≥35dB
    Inserion Loss<0.3db
    Channels numberSimplex (12Fiber)
    Cable materialLSZH,PE
    Housing MaterialPlastic,Metal
    No. of Fiber8/12/24
    Operating temperature-40℃~85℃
    CertificationCE/ROHS/ISO9001


    Single Mode Green Small Fiber Optic Adapters MPO To APC Without Flange
